Elegant - 67 Series (uPVC Casement Windows)

Overview

The most popular style of windows used in India is outward open able Window. We can open the casement window outward or inward. Casement Windows offer best ventilation since they open outward - almost 85° and ensure complete sealing from dust, noise and other pollutants. Multi-chamber design of the profile reduces the transfer of the heat thus saves energy. All the casement windows are steel reinforced for added strength. The multi-locking system ensures better security & safety.

Casement Windows can be made in various designs:-

Side Hung

Top Hung

Casement Window with integrated grill

Casement Window with integrated grill and mesh

Tilt & Turn Window

Window Design

Fixed Window

Side Hung One Sash

Side Hung Two Sash

Both Side Fixed Window

Side Hung Two Sash

Both Side Hung Sash With Middle Fixed

Side Hung Top & Down Fixed

Side Hung Two Sash With Top Fixed

Side Hung Tripe Sash With Top Fixed

Four Sash Side Hung With Top Fixed

Top Hung

Fixed Window With Lover

Fixed Window With Lover & Exhaust Provision

Side Hung With One Side Fixed Window

Profile Drawings

Casement Frame

Casement Sash

Sash / Mullion Window

Sash / 'z' Mullion

Sash / Style

't' Profile

Single Beading

135° corner coupler

90° straight corner profile

90° corner profile

Coupling Profile

Baypole

Baypole Adaptor

^*All the profile drawings are conceptual.

Detailed Cross Section

Glass Option

Float Glass

Float glass is prepared by pouring molten glass onto one end of a molten tin bath. The glass floats on the tin, and levels out as it spreads along the bath, giving a smooth and bright face to both sides.

Tinted Glass

Designed primarily to prevent bright sunlight and high-energy visible light from discomforting the eyes.Tinted or reflective glass reduces the infiltration of sunlight and heat.

Toughened Glass

Toughened (or tempered) glass enhances security. It is used when strength, thermal resistance and safety are important considerations. Toughened glass is typically having four to six times more strength than of normal glass.

Doubled Glazed Toughened

Toughened glass is used for the two layers of glazing that is separated by a spacer along the edge and sealed to create a dead air space between the layers. This type of glazing has functions of thermal insulation and noise reduction.

Reflective Glass

This type of glass is manufactured by applying a reflective coating to block the incoming heat radiation from the sun, while allowing natural light in. Reflective glass is solar efficient, energy efficient & highly durable.

Low "E" Glass

The Advanced Solar Control and Thermal Insulation (low e) Glass is manufactured by deposition of multiple layers of highly specialized nano-metric metallic oxides under vacuum conditions.

This low e reflective glass is made up of select coatings and is ideal for modern architecture which demands exterior glazing solutions with a neutral appearance.

Hardware Option

Different types of imported locks are available for different types of windows and doors that suit to different needs.

Butt Hinge

Friction Stay

Single Point Handle

White Handle

White Handle With Key

Arm Stay

Transmission Gear

2d Hinge

Shoot Bolt

^*These hardwares may vary as per availability of the production.

Reinforcement

Coupling

Coupling profiles are used for making combination windows :-

Combination of casement and sliding frame with coupling.
Combination of casement and fixed frame with coupling.
Combination of sliding and fixed frame with coupling

There are various other combinations available.

90° corner assembly

135° corner assembly

Accessories

Drainage Cap

Fastener

Fastener Cap

Glass Packer

Screw

Lifting Board

Shoot bolt

^*These accesories may vary as per availability of the production.

Mesh

Fiber Mesh

Most commonly used window mesh material, it does not corrode, rust, dent or unravel. It is flexible, economical and easy to install solution

SS Mesh

Made of stainless steel wires woven into a mesh. It is extremely durable and has superior strenth. It comes in black colour, offers excellent outdoor visibility - "uninterrupted view, better air-flow and excellent resistance to rust and corrosion.

Roll on Mesh

A lighter mesh variant that rolls up and opens down with one swift movement. It comes fitted with high quality imported mechanism that ensures smooth and easy movement of mesh frame. It is best suited for casement outward opening windows, ventilators, kitchen windows and bathroom windows.
